High Quality Core Components

Stable and reliable for a long time

Modules Of Design

Easy to assembly and
maintain

The Powder Feeding Structure

Accuracy of powder feeding,
replacement of different metal powders

Multi-scraper Adaptable

Rubber, hairbrush, high-speed steel, ceramic

Adjustable Parameters

Built-in parameters
adjustable according to needs

Open-source Parameters

The parameters available for editing and directly use for customer

Real-time monitoring

Real-time recording, output, self-diagnosis

Customer Service

Support the special service for customer

Materials

Build Size

Laser Type

Scanning System

Beam Focus System

Beam Quality

Beam Focus Diameter

Max Scanning Speed

Layer Thickness

Powder spreading

Gas Protection

Oxygen Content

Efficiency

Host Dimension

Installation Dimension

Power Supply

Power Consumption

CoCr alloys, Ti and Titanium Alloys, Refractory Metals, Intermetallic Compounds, etc.

φ170mm×120mm (D×H)

Customized: max 140mm~150mm (H)

500W Single/ Dual Fiber Laser

High-speed galvanometer

F-theta field lens

M²<1.1

40~80μm ( size adjustable )

7m/s

20~100μm ( Layer thickness adjustable)

One-way variable speed powder spreading

Ar/N₂

≤100ppm

30cm³/h (single laser, related to the shape, size, material and parameters of the part)

61cm³/h (dual laser, related to the shape, size, material and parameters of the part)

1400mm×800mm×1600mm (W×D×H)

3200mm×2400mm×2180mm (W×D×H)

AC220V

7KW (single laser) ; 9KW ( dual laser)
